The output from a NAND gate having inputs A and B given below will be,

The output from a NAND gate having inputs A and B given below will be,



Solution

The output of NAND gate is

Y=(AB)'.

The truth table is

ABY001011101110

Y would be zero only when both A and B are 1 . Clearly, for all other input conditions the output will be 1. Hence, this is the right option.

Asked in: JEE Main 2023 (13 Apr Shift 2)
